Zoomlion Concrete Truck Mounted Pump Accessories Hinge Seat With A Diameter Of 60

Product Description

​Design and Structure

Precise Dimensions: The φ60 hinge seat is designed with exacting precision. The diameter of 60mm is a crucial measurement that ensures a proper fit within the context of the Zoomlion concrete truck - mounted pump's mechanical structure. The tolerances are kept to a minimum to guarantee seamless integration with other components, such as the pump's boom or support arms.

Robust Material Selection: It is typically crafted from high - quality materials, like alloy steel or a high - strength composite. These materials are chosen for their excellent mechanical properties, including high tensile strength and hardness. This enables the hinge seat to endure the significant forces exerted during the operation of the concrete pump. The material also provides good resistance to fatigue, which is essential for withstanding the repeated loading and unloading cycles that occur during normal use.

Thoughtful Design Details: The hinge seat features a well - designed shape with carefully placed connection points and mounting holes. These elements are designed to facilitate easy assembly and secure attachment to other parts of the pump. The overall geometry of the hinge seat is optimized to distribute forces evenly, reducing stress concentrations and enhancing the overall structural integrity of the connection.

Working Principle

Connection and Articulation: The primary function of the φ60 hinge seat is to serve as a connection joint. It allows different parts of the concrete truck - mounted pump, such as the boom sections, to articulate and rotate relative to each other. This enables the pump to achieve a wide range of working positions, which is crucial for accurately placing concrete in various construction scenarios. The hinge seat's design ensures smooth and controlled movement, minimizing any unwanted vibrations or jerks.

Force Transmission: As the pump operates, a variety of forces come into play. The weight of the boom, the pressure exerted during the concrete pumping process, and the dynamic forces due to the movement of the vehicle are all transmitted through the hinge seat. It acts as a reliable medium to transfer these forces from one component to another. By distributing the forces evenly across its structure, the hinge seat helps to maintain the stability and balance of the pump during operation.

Performance Features

High Load - Bearing Capacity: Despite its relatively compact size with a diameter of φ60, the hinge seat has a remarkable load - bearing capacity. It is engineered to handle heavy loads without deformation or failure. This capacity is vital for the safe and efficient operation of the concrete truck - mounted pump, as it ensures that the pump can perform its functions even under demanding conditions, such as when pumping high - volume concrete over long distances.

Low Friction and Long - Lasting: The surface of the hinge seat is designed to minimize friction. This is achieved through advanced surface treatments or the use of self - lubricating materials. Reduced friction not only results in smoother movement of the connected parts but also significantly reduces wear and tear. As a result, the hinge seat has a longer service life, reducing the need for frequent replacements and maintenance, which in turn saves costs and downtime.

Resistance to Harsh Environments: Concrete truck - mounted pumps operate in a variety of challenging environments. The φ60 hinge seat is designed to resist the effects of these harsh conditions. It has excellent resistance to corrosion from chemicals in the concrete, moisture, and dust. This resistance ensures that the hinge seat remains in good working condition over an extended period, maintaining the performance and reliability of the pump.
