Transfer Case Cylinder Screw M5 * 100 for Zoomlion Concrete Pump Truck Accessories

Design and Construction

Precise Dimensions: The M5*100 transfer case cylinder screw is designed with exacting precision. The "M5" indicates a metric thread size with a nominal diameter of 5mm, and the "100" represents the length of the screw in millimeters. These specific dimensions are carefully engineered to ensure a proper fit and secure fastening within the context of the concrete pump truck's transfer case cylinder.

Quality Material: It is typically made from high - quality metal alloys. The material selection is crucial as it provides the necessary strength and durability. These alloys have excellent tensile strength to withstand the forces exerted during the operation of the pump truck. They also have good resistance to corrosion, which is important given the often - harsh and humid conditions that construction equipment may face.

Working Principle

Fastening Function: The primary purpose of this screw is to provide a reliable fastening mechanism. It is used to hold together various components of the transfer case cylinder. When tightened, it creates a clamping force that keeps the parts in place, ensuring the integrity of the cylinder assembly. This is essential for the proper operation of the transfer case, as any loosening of the components could lead to leaks or inefficiencies in the system.

Thread Engagement: The metric threads on the screw engage with corresponding threaded holes or nuts. The precise threading allows for a tight and secure connection. As the screw is turned, the threads grip the mating part, and the frictional force generated helps to maintain the connection, even under the vibrations and dynamic loads that the pump truck experiences during operation.

Performance Features

Strength and Reliability: The M5*100 screw is designed to provide sufficient strength to keep the transfer case cylinder components firmly attached. It can withstand the mechanical stresses associated with the normal operation of the concrete pump truck. This reliability is vital to prevent any accidental disassembly of parts, which could lead to costly repairs and downtime.

Corrosion Resistance: Due to its material properties, the screw is resistant to corrosion. This is beneficial as it can maintain its structural integrity and functionality over an extended period, even when exposed to moisture, chemicals, or other corrosive substances that may be present in a construction environment.

Easy Installation and Removal: The standard metric design of the screw makes it relatively easy to install and remove using common tools. This simplifies maintenance and repair procedures for the transfer case cylinder. Technicians can quickly and efficiently replace or adjust the screws as needed.
