Product Details:
|
|
Place of Origin: | Changsha,Hunan,China |
---|---|
Brand Name: | Sany |
Model Number: | SYM5352THB 520C-10 |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 1pcs |
Price: | Negotiable |
Packaging Details: | Standard Export Package |
Delivery Time: | 22 day |
Payment Terms: | L/C,D/A,D/P,T/T |
Supply Ability: | 1pcs/month |
Detail Information |
|||
Condition: | Used | Color: | Red |
---|---|---|---|
Keyword: | Concrete Pump Truck | After-sales Service Provided: | Video Technical Support |
High Light: | Rexroth Dual Main Oil Pump Truck,Sany Volvo C10 Pump Truck,52meter Concrete Pump Truck |
Product Description
Features and advantages of pump truck
1. Wide scope of operation
Lightweight technology: realize 10% weight reduction, "under the law" long-boom pump truck
2. Low fuel consumption
·Cast energy-saving main valve: response and reversing speed increased by 20%, reversing impact decreased by 10%, and service life of hydraulic parts increased by 50%.
·Self-matching of engine power: the pump displacement is adjusted adaptively with the engine speed, power, torque and fuel injection quantity, and the engine speed is dynamically and reasonably matched according to the load change, so that the engine always works in the fuel-efficient area.
3. High efficiency
·Fast suction: the installation angle of the pumping system is optimized from 10-11 degrees to 8 degrees, and the suction efficiency is increased by 10%, and the measured value is up to 95.2%.
·Fabric fast: new 6RZR folding boom
4. Security
·External connecting rod and through-axle structure: the connecting end of the boom is more rigid, with better handling, and the swing amplitude of rotation is reduced by more than 20%; The end vibration amplitude can be controlled within ± 20cm.
·The turntable and the boom are connected through the shaft structure: the connection rigidity is better, which is beneficial to the vibration reduction and anti-swing of the boom.
·New and optimized delivery pipe support: the stress at each point is less than 100MPa, without cracking.
·The reducer is equipped with plunger motor: the rotary positioning is more accurate, the control is more safe and reliable, and the accuracy is increased by 0.7-1.5 times.
·All-round online monitoring: reversing camera, reversing image
5. Intelligence
·Digital oil cylinder: the utilization rate of master oil cylinder stroke can reach 99.5%, realizing adaptive stroke correction and intelligent fault diagnosis.
·Mobile APP Sany customer cloud
The device location information and driving path can be viewed in real time on the mobile terminal;
Basic parameters such as equipment working condition, fuel consumption, pumping working time, standby time
Pump truck parameter information | |
Type | SYM5352THB 520C-10 |
Boom length(m) | 48-52 |
Maximum engine power kW/(r/min) | 337/1400-1900 |
Chassis | Volvo |
Vehicle mass (Kg) | 35000 |
Overall dimensions of the whole vehicle (length x width x height) mm | 12200×2550×4000 |
Maximum theoretical conveying capacity (m3/h) | 180 |
Maximum outlet pressure of concrete (MPa) | 13 |
Chassis model | FM460 64R B |
Engine model | D13C460S EUV |
Emission standard | Country V |
Displacement(L) | 12.777 |
